Structural Plywood
Prabal_Structura_Product_logo

Structural Plywood

Prabal Structura is our IS 10701 structural grade plywood. It is built for projects where plywood must do more than finish a surface, it must hold its form, carry load, and stay true over time. Designed with a balanced build for anti-bend dimensional stability, Structura delivers warp-resistant performance that supports demanding spans and high-stress applications.

At its core is a high-density HD Gurjan-rich construction paired with a premium Gurjan face veneer, giving you stronger screw-holding and a cleaner working surface. Add pressure-treated durability and a high-strength PF resin system engineered for load-bearing performance, and you get a board that remains dependable long after installation.

Prabal Structura – Strength that stays aligned.

4mm, 6mm, 9mm, 12mm, 16mm, 19mm, 25mm
8' x 4'
Prabal_Ico_AccArtboard
5 (4mm), 5 (6mm), 7 (9mm), 9 (12mm), 11 (16mm), 13 (19mm), 17 (25mm)

Structural Plywood

Prabal Structura is our IS 10701 structural grade plywood. It is built for projects where plywood must do more than finish a surface, it must hold its form, carry load, and stay true over time. Designed with a balanced build for anti-bend dimensional stability, Structura delivers warp-resistant performance that supports demanding spans and high-stress applications.

At its core is a high-density HD Gurjan-rich construction paired with a premium Gurjan face veneer, giving you stronger screw-holding and a cleaner working surface. Add pressure-treated durability and a high-strength PF resin system engineered for load-bearing performance, and you get a board that remains dependable long after installation.

Prabal Structura – Strength that stays aligned.

4mm, 6mm, 9mm, 12mm, 16mm, 19mm, 25mm
8' x 4'
Prabal_Ico_AccArtboard
5 (4mm), 5 (6mm), 7 (9mm), 9 (12mm), 11 (16mm), 13 (19mm), 17 (25mm)

Formaldehyde Emission

E0 Compliant
Safe for indoor use, low VOC, healthy for families and workspaces

Preservative Treatment

Advanced Copper Chrome (VPT)
Anti-borer, Anti-termite, Anti-fungal protection

Product Warranty

LIFETIME
Built with calibrated precision and protected by a lifetime assurance of reliability

Product Price Category

Premium Economy
Engineered for dependable performance and everyday applications

Standard Product Features

Prabal_Feature_BlazeBlock_G
BlazeBlock™
Fire-resistant build that supports safer performance in heat-prone applications
Prabal_Ico_AquaFendTech
AquaFend Tech™
100% Boiling Water Proof protection to resist swelling and moisture damage
Prabal_Feature_XtermPlus_G
XTerm Plus Tech™
Smart defense against termite and borer attacks.
Prabal_Feature_TrueGaugeDuo_G
TrueGauge Duo™
Both-side calibrated for consistent thickness and cleaner finishing.
Prabal_Feature_CoreTitanDensity_G
CoreTitan Density™
HD Gurjan-rich core for higher density and superior screw-holding strength
Prabal_Feature_PressEdge_G
PressEdge Pro™
4-times pressed for a tighter build and improved core integrity
Prabal_Feature_LuxEdge_G
LuxEdge Finish™
Polished to perfection, smooth to the last detail.
Prabal_PowerLayerLock_G
Power LayerLock™
High-strength PF resin formulation for load-bearing bonding and durability
Prabal_Feature_BlazeBlock_G
BlazeBlock™
Fire-resistant build that supports safer performance in heat-prone applications
Prabal_Ico_AquaFendTech
AquaFend Tech™
100% Boiling Water Proof protection to resist swelling and moisture damage
Prabal_Feature_XtermPlus_G
XTerm Plus Tech™
Smart defense against termite and borer attacks.
Prabal_Feature_TrueGaugeDuo_G
TrueGauge Duo™
Both-side calibrated for consistent thickness and cleaner finishing.
Prabal_Feature_CoreTitanDensity_G
CoreTitan Density™
HD Gurjan-rich core for higher density and superior screw-holding strength
Prabal_Feature_PressEdge_G
PressEdge Pro™
4-times pressed for a tighter build and improved core integrity
Prabal_Feature_LuxEdge_G
LuxEdge Finish™
Polished to perfection, smooth to the last detail.
Prabal_PowerLayerLock_G
Power LayerLock™
High-strength PF resin formulation for load-bearing bonding and durability

Super Feature

Prabal_Feature_SeemlessCore_G
Seamless Core™ – Every sheet is built using full-length core layers that are precisely composed and tightly stitched, ensuring perfectly aligned cores, zero gaps, no overlaps, and uncompromised structural strength.
Prabal_Feature_SeemlessCore_G

Super
Feature

Seamless Core™ – Every sheet is built using full-length core layers that are precisely composed and tightly stitched, ensuring perfectly aligned cores, zero gaps, no overlaps, and uncompromised structural strength.

Ideal Applications

Mezzanine Loft

Loft Storage

Loft Storage

Warehouse Racks

Warehouse Racks

Site Office Cabin

Site Office Cabin

Stage / Event Platform Decking

Stage / Event Platform Decking

Truck Cargo Box Interior Lining

Truck Cargo Box Interior Lining

Know Your

Structura

Industry Standard

0 to +6mm tolerance

Structura

2443mm max

Industry Standard

0 to +3mm tolerance

Structura

1221mm max

Industry Standard

±5%

Structura

±2% (High Precision)

Industry Standard

≤ 2mm/1000 mm

Structura

1mm/1000 mm

Industry Standard

≤ 2mm/1000 mm

Structura

2mm/1000 mm

Upgrade Quotient

Upgrade from other structural Ply to Prabal Structura when the brief moves to structural stability with pressure-treated durability that help reduce bending/sagging risks and improve screw-holding in high-stress applications.
Core Quality & Construction
Built with zero-compromise workmanship for consistent performance.
Parameters
Industry
Structura
Splits / Gaps / Open Joints
NIL
NIL (Gap-Free Core)
Moisture Content
5–15%
6.5–10% (Optimised Stability)
Specific Gravity
0.6 – 0.7
0.75– 0.8
Water Absorption
-----
< 4% (Low Swell Protection)
Idea-Ico
WHAT THIS MEANS:
Better load bearing, fewer dimensional changes, and longer life.
Mechanical Strength Performance (AVG)
Static Bending Test (Dry State): Flexural Strength & Elasticity
Parameters
Industry
Structura
MOR Along Grain
50 N/mm²
>56 N/mm²
MOR Across Grain
30 N/mm²
>40 N/mm²
MOE Along Grain
7500 N/mm²
>7800 N/mm²
MOE Across Grain
4000 N/mm²
>5200 N/mm²
Idea-Ico
WHAT THIS MEANS:
Excellent load resistance without bending, warping, or cracking
Mechanical Strength Performance (MIN)
Static Bending Test (Dry State): Flexural Strength & Elasticity
Parameters
Industry
Structura
Min MOR Along
45 N/mm²
>50 N/mm²
Min MOR Across
27 N/mm²
>35 N/mm²
Min MOE Along
6700 N/mm²
>7500 N/mm²
Min MOE Across
3600 N/mm²
>4200 N/mm²
Idea-Ico
WHAT THIS MEANS:
Excellent load resistance without bending, warping, or cracking
Wet Strength Tests
Designed for kitchens, bathrooms, exteriors, and moisture-heavy conditions.
Parameters
Industry
Structura
Wet MOR
22 N/mm²
>26 N/mm²
Wet MOE
3750 N/mm²
>3975 N/mm²
Idea-Ico
WHAT THIS MEANS:
Maintains structural integrity even after prolonged water exposure
Glue Shear Strength (GSS)
Superior bonding ensures long-term durability.
Parameters
Industry
Sructura
GSS Dry
≥1350 N
>1500 N
GSS Wet
≥1100 N
>1250 N
GSS Microbial
≥1000 N
>1150 N
Idea-Ico
WHAT THIS MEANS:
A bond that resists boiling water, humidity, and microbial attack
Tensile Strength
High resistance to internal stress and pull forces.
Parameters
Industry
Structura
Along Grain
55 N/mm²
>60 N/mm²
Across Grain
35 N/mm²
>42 N/mm²
Idea-Ico
WHAT THIS MEANS:
It ensures the ply won’t delaminate or tear under stress
